Description
Available to buy online, this throat plate fits both the ESSE 100 and 200 models. Constructed from 3mm thick steel this plate measures 520mm (w). Not suitable for the 200XK model nor interchangeable with brick baffles.
To fit an ESSE 100 / 200 Throat Plate follow these instructions. See alternative image.
- Remove baffle and old firebricks
- Insert Right Hand Firebrick
- Followed by the Right Hand Side Rear Firebrick
- Replace Throat Plate
- Left Hand Rear Fire Brick
- Lastly, Left Hand Side Brick
How to tell the difference between an ESSE 100 and 200 model.
Aftermarket Part.
